Additional Equipments

Aggregate Capacity & Discharge : 3 x 10 m3
Door Opening System : Pneumatic (supported by Compressor 300 lt)
Door Feeder / Vibration Unit : 3 x 0,5 kw Vibrators
Operation System : By PLC System (ATS Weighing Sytem + 4 loadcells)
Dimension : length = 9500mm / width = 2250mm / height = 3520mm
Weight : 6558 kgs

Pres Makina aggregate Hopper are designed and manufactured for heavy duty operation in accordance
with related DIN norms. The electro-pneumatically controlled valves provide easiness and options in
discharge. They also create an elevation that decreases ramp building costs and operation costs by
helping the materials to slide and reduce friction and wear.


Aggregate Discharge Capacity : 25 ton / Hour
Motor Power & Transmission Gear : 5,5 kw @ 104 rev/min - Brand / YILMAZLAR
Rubber Belt : 4 times coated
Load Cell : 4 x 2.000 kgs
Operation System : By PLC System (ATS Weighing Sytem + 4 loadcells)
Dimension : Length = 10200 mm / Width = 1050 mm / Height = 500 mm
Weight : 820 kgs

Silo Capacity : 75 Ton
Level Indicator : Up and Bottom
Plate Thickness : 4 – 6 mm
Cement Silo Top Filter : Including all equipments
Cement Silo Materials : Silo Legs = NPL 80 / Silo Body = NPU 80
Operation System : By PLC System
Dimension : Height = 16262 mm / Diameter = Ø 3060 mm
Weight : 7300 kgs

Type : Universal Input Type
Motor Power : 11 kw
Operation System : By PLC System
Dimension : Lenght = 8000 mm / Diameter = Ø 219 mm
Capacity : 12 ton per hour

Weighing Capacity : 40 – 200 kgs
Load Cell : 1 Unit
Pneumatic Valve : 1 Unit
Operation System : By PLC System

Weighing Capacity : 10 – 1000 lt
Load Cell : 1 Unit
Pneumatic Valve : 1 Unit
Operation System : By PLC System

Water pump power : 2 HP
Operation System : By PLC System

Descriptions Model : DKC 500
Working Pressure : 8 Bar / 115 Psi
Motor Power : 5,5 kw / 7,5 HP
Connection : ¾”
Operation System : By PLC System
Dimension : Length = 642 mm / Width = 1934 mm / Height = 1308 mm
Weight : 308 kgs

The Latch Conveyor is transporting the stacked blocks (Blocks has been stacked by Product Collecting
Robot “Cubber Robot”) to side so that workers can strap the blocks and the forklift driver is able to
collect the stacked blocks into the stock area or directly into the truck.

The front full pallet stacking robot (elevator robot) will take the fresh manufactured product and will
stack it top on top max. 8 pallets. The Forklift Driver will take the pallets into the drying & irrigation area.

The pallet unloader (lowerator robot) is taking dried products pallets max. 8 pallets and forward them
into the product collecting robot (cubber robot) where blocks will taken from the pallets.

The Product collecting Robot (Cuber Robot) is collecting the dried blocks from the pallets and stack it
into the Elevator 6 floors.

The Generator will be min. 275 KVA all specifications mention in the catalogue separately.
